Fuse link CH8x32 gG 0,5A/400V 002651000

Specifications

ETI Code:
002651000
Description:
CH8x32 gG 0,5A/400V
Class name:
Fuse link
Type:
CH
Size:
8x32
Rated current (A):
0,5
Rated AC voltage (V):
400
Characteristics:
gG
Breaking capacity AC (kA):
20
Application:
For cable protection
Power dissipation (W):
0,55
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838400115706
Net weight of the product
0.004  kg
Customs tariff
85361010

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838400094124
Basic packaging weight
0.046  kg

Transport packaging

Transport packaging quantity
2500
EAN code for a transport packaging
3838400094131
Transport packaging weight
11.871  kg
Pallet quantity
80000
Classification
EC000035
Class name
Miniature fuse
Voltage type
AC
Rated current
0,5A
Rated voltage
400V
ETIM Classification – Version 7.0
