Surge arresters are essential for protecting electrical and electronic equipment from overvoltages. Selecting the appropriate surge arrester and understanding its key parameters ensures optimal protection. ETI ETITEC offers a comprehensive range of high-quality surge arresters to meet various application needs.

002443040

Image of ETITEC V T2 440/20 1+0

ETITEC V T2 440/20 1+0 Surge arrester

ETI Code:: 002443040
Function:: SPD
Surge arrester type:: T2
Uc Continous Operating Voltage AC:: 440 V
Nominal Discharge Current (8/20 μs) In:: 20 kA
Max. Discharge current Imax, 8/20:: 40 kA
Current type:: AC
Rated AC voltage:: 400
Up - Voltage Protection Level:: 2.5 kV
Remote signalisation:: ✗
Leakage Current:: ✗
Network system:: IT
Number of modules:: 1
Built-in depth:: 67 mm
IP rating:: IP20
Applied Technology:: MOV
Catalogue Group:: ETITEC V

Product

Net weight of the product: 0.107 kg
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838400178350
Basic packaging weight: 0.118 kg
Basic Packaging Dimensions Height: 70 mm
Basic Packaging Dimensions Width: 20 mm
Basic Packaging Dimensions Depth: 100 mm
Basic packaging volume: 0.14 dm³

Transport Packaging

Intermediate packaging quantity: 8 pcs
EAN code for a intermediate packaging: 3838400178343
Intermediate packaging weight: 1.049 kg
Intermediate Packaging Dimensions Height: 78 mm
Intermediate Packaging Dimensions Width: 105 mm
Intermediate Packaging Dimensions Depth: 183 mm
Transport packaging quantity: 24 pcs
EAN code for a transport packaging: 3838400178336
Transport packaging weight: 13.348 kg
Transport Packaging Dimensions Height: 290 mm
Transport Packaging Dimensions Width: 210 mm
Transport Packaging Dimensions Depth: 460 mm
Transport packaging volume: 28.014 dm³
Pallet quantity: 960 pcs
Customs tariff: 85363030
